4
Service
Manual
BIO meter AL-100
Doc. No
4. How to disassemble.
(1) Remove 6 sets of screws (M3*8) from
rear cover.
Remarks: Keep the washer that
comes from bottom side of rear cover.
(2) To remove rear cover, remove 6 sets
of screws (M3*6) that hold rear cover.
<Page 04>
