TH2821A OPERATION MANUAL
19
3. Range Setup:
U, V and AUTO keys are used to set the measurement
range. AUTO key toggles ranging mode between “Auto”
and “Hold”. U and V keys are used to increase or
decrease the measurement range, if the current ranging
mode is “Auto”, then the ranging mode is changed to
“Hold” at the same time.
* Note：
When ranging mode is set to HOLD, the measurement
range is fixed at current range. Overload symbol “-----” will
be displayed if the impedance under test exceeds the
current effective measurement range or display range.
Range
No.
Range
Resistor
Range
Up
Range
Down
0
100kΩ
1
10kΩ
2
1kΩ
3
100Ω
4
20Ω
Ï
20kΩ
Ï
2kΩ
Ï
200Ω
Ï
20Ω
Ï
Ð
18kΩ
Ð
1.8kΩ
Ð
180Ω
Ð
18Ω
Ð
Table 4-2 Ranges
