1.3 Specifications
Parameter L-Q, C-D, R-Q and Z-Q
Frequency 100 Hz, 120 Hz , 1 kHz and 10 kHz
Accuracy
Basic Accuracy: 0.3%
Display
5 digits display for both primary and secondary
parameters
100 Hz,120 Hz
1 µH – 9999 H
L
1 kHz,10 kHz
0.1 µH – 999.9 H
100 Hz, 120Hz
1 pF – 9999 µF
C
1kHz,10 kHz
0.1 pF – 999.9 µF
R, |Z|
0.0001 Ω - 999.9 MΩ
D, Q 0.0001 – 9999
Measurement
Range
∆%
0.0001% - 9999%
10kHz
0.1 Vrms (1±15%)
120Hz
1kHz
0.3 Vrms (1±15%)
Test Level
(Range Auto
and Open
Circuit)
100Hz
0.42 Vrms (1±15%)
Ranging Mode Auto and Hold
Equivalent
Circuit
Parallel and Series
Display
Direct, ∆ABS and ∆%
Correction Open and Short Zeroing
Rate Approx. 3 meas/sec
Terminals 5 terminals
