• Battery test result
Result Results found Analysis
Battery in good condition
GOOD & PASS
VOL : xx.xx V
CCA : xxxx CCA/SAE
IR : xx.xx mΩ
The battery is operational.
Good condition, to be recharged
GOOD & RECHARGE
VOL : xx.xx V
CCA : xxxx CCA/SAE
IR : xx.xx mΩ
Battery in good condition but low current.
To recharge before any use.
Warning
CAUTION
VOL : xx.xx V
CCA : xxxx CCA/SAE
IR : xx.xx mΩ
The battery must be maintained. It gradually
weakens the starting capacity of the engine.
There may also be a bad connection between the
vehicle and the battery. Monitor the battery for a
possible replacement.
Charge & test
RECHARGE & RETEST
VOL : xx.xx V
CCA : xxxx CCA/SAE
IR : xx.xx mΩ
The battery discharges quickly and is no longer
functional. Replace the battery.
To replace
BAD & REPLACE
VOL : xx.xx V
CCA : xxxx CCA/SAE
IR : xx.xx mΩ
The battery discharges quickly and is no longer
functional. Replace the battery.
Defective cells to replace
BAD CELL & REPLACE
VOL : xx.xx V
CCA : xxxx CCA/SAE
IR : xx.xx mΩ
At least one of the cells in the battery is in
short-circuit. Replace the battery.
Charge error
LOAD ERROR
VOL : xx.xx V
CCA : xxxx CCA/SAE
IR : xx.xx mΩ
The battery exceeds 2,000 CCA or 200 Ah, or the
clamps are not connected properly. Fully charge
the battery and retest after discarding the other
two causes. If the display remains the same, the
battery must be replaced.
• Display of the state of charge and the state of health of the battery
1. Press the directional buttons to view the SOC (charge status) and SOH (health status) of the battery.
2. Press «ENTER» to return to the main menu.
TEST OF THE ALTERNATOR CHARGING SYSTEM
1. Select «system test» in the main menu.
2. Ensure that all consumers are o, such as headlights, lights, air conditioning, radio etc. before starting the engine.
3. When the engine is running, one of the following 3 results is displayed :
Results displayed
Analysis
Starting normal volts The voltage is normal. Press "ENTER" to perform load circuit test
Low starting voltage The voltage is below the limit. Tune the starter in line with the proce-
dure supplied by the manufacturer.
No starting voltage detected The starting voltage is not detected. Start the engine again.
4. Press «ENTER» to begin the charging system test.
9
BATTERY TESTER DBT 350
