SYSTEM TEST:
1. Select “SYSTEM TEST” from the main menu.
SYSTEM TEST
xx.xx V
2. Turn off all vehicle accessory loads such as light, air conditioning, radio,
etc. Before starting the engine.
TURN OFF LOADS
START ENGINE
3. When the engine is started, one of the three results will be displayed along with the actual reading measured.
CRANKING VOLTS NORMAL
Thesystemisshowingnormaldraw.Press«ENTER»toperformthechar-
ging system test.
CRANKING VOLTS
xx.xx V NORMAL
VOLTS BEIM ANLASSEN LOW
Thecrankingvoltageisbelownormallimits,troubleshootthestarterwith
manufacturers recommended procedure.
CRANKING VOLTS
xx.xx V LOW
VOLTS BEIM ANLASSEN NOT DETECTED
Thecrankingvoltageisnotdetected.
CRANKING VOLTS
NOT DETECTED
4.Press«ENTER»tobeginchargingsystemtest.
PRESS ENTER FOR
CHARGING TEST
MAKE SURE ALL LOADS
ARE OFF
5.Pressthe«ENTER»key,oneofthethreeresultswillbedisplayedalongwiththeactualreadingmeasured.
HIGH CHARGING VOLTS WHEN TEST AT IDLE
The voltage output from the alternator to the battery exceeds the normal
limitsofafunctioningregulator.Checktoensurethereisnolooseconnec-
tion and the ground connection is normal.
ALT. IDLE VOLTS
xx.xx V HIGH
If there is no connection issue, replace the regulator. Since most alternators have the regulator built-in, this
will require you to replace the alternator. The normal high limit of a typical automotive regulator is 14.7 volts
+/-0.05.Checkmanufacturerspecicationsforthecorrectlimit,asitwillvarybyvehicletypeandmanu-
facturer.
CHARGING SYSTEM NORMAL WHEN TEST AT IDLE
The system is showing normal output from the alternator. No problem is
detected.
ALT. IDLE VOLTS
xx.xx V NORMAL
