Tool Shed TSPHB5 - Specifications; Product Identification

4
5
OPERATION MANUAL OPERATION MANUAL
WWW.THETOOLSHED.CO.NZWWW.THETOOLSHED.CO.NZ
SPECIFICATIONS
PRODUCT IDENTIFICATION
CC Rating 51.7 cc/rev
Drive Shaft Capacity Up to 200mm Ø Maximum
Engine Type 2-Stroke Single Cylinder Petrol Engine
Fuel Tank Capacity 1.2 Litre
Fuel Mixture 25:1 (Petrol:Oil)
Gear Ratio 34:1
Machine Weight 10 KG
Auger Weight 2 KG
1
Fuel Tank
2
Trottle Switch
3
Pull Start Cord
4
Engine
5
Handle
6
200mm Auger (Supplied)
7
Fuel Mixing Bottle
8
Spark Plug Spanner
9
Allen Keys
10
Double Open-End Spanner
11
Phillips Head Screwdriver
Note:
2-Stroke Oil mix only with a mix of 25-to-1 is to be used in this engine.
3
4
5
1
2
6
7 8 9
10 11
