TOORX BRX Compact MultiFit - Hardware Identification Chart

HARDWARE IDENTIFICATION CHART
Figure No. Description Qty
D5
D8
Carriage Bolt (M8*1.25*60mm)
Carriage Bolt (M8*1.2548 mm)
4
2
D7 Bolt, Button Head (M8* 40 mm) 4
D17 Screw, Round Head (M6 x 1 x 12mm) 1
D22 Acorn Nut (M8) 4
D23 Arc Washer (M8) 4
D24 Washer (M8) 6
D25 Nut M8 2
D1 Adjustment Knob 2
D2 Pull Pin 1
