TOORX BRX Compact - Page 13

TOCONTACTCUSTOMERSERVICE
19
B37 Stopper 1
B38 Endcap 2
B39 Bearing Housing 2
B40 Hand grip 2
B43 Grommet Plug 4
B44 Plug 1
C. Electrical parts
No. Description QTY
C1 Meter 1
C2 Connection Wire 1
C5 Left Crank 1
C6 Right Crank 1
C7 Flywheel 1
C8 V-Ribbed Belt (230J) 1
C9 V-Ribbed Belt(240J) 1
C10 Pulley w/ Shaft 1
C11 Pulley Shaft 1
C12 Pulley 1
C13 Sensor 1
C14 Ball Bearing (6000ZZ) 2
C15 Ball Bearing (6200ZZ) 1
C16 Ball Bearing (6003ZZ) 2
C17 Idler Shaft 1
C18 Magnet 6
C19 Idler Shaft 1
C20 Magnet 1
C21 Hand Pulse 4
C22 Hand pulse Line
1
D. Hardware
No. Description QTY
D1 Adjustment Knob 1
D2 Pull Pin 1
D4 Allen Wrench 1
D5 Carriage Bolt M8*60 4
D6 Hex Head Bolt M6*45 2
D7 Bolt, Button Head M8*40 4
D8 Carriage Bolt M8*48 2
