HARDWARE IDENTIFICATION CHART
adyattachedtothepart.
Figure No. Description Qty
D5
D8
Carriage Bolt (M8 * 1.25 * 60mm)
Carriage Bolt (M8 * 1.25 x*48mm)
4
2
D7 Bolt, Button Head (M6*1 *40mm) 4
D52 Bolt, Button Head (M6* 12mm) 4
D53 Spring Washer (M6) 4
D22 Acorn Nut (M8*1.25) 4
D23 Arc Washer (M8) 4
D24 Washer (M8) 6
D25 Nut M8 2
D1 Adjustment Knob 1
D2
Pull Pin
1
