TOORX BRX35 - Page 3

4
ASSEMBLY INSTRUCTIONS
Step 1
Assembly the rear and front stabilizer (F&E)
with 4 bolts (I-6), 4 nuts (I-8) and 4 washers
(I-7).
Step 2
Assemble the left hand pedal (H-L) and the
right hand pedal (H-R) to the hand crank.
Step 3
Connect the saddle (G-3) and the slider
(G-5) with three bolts and washers.
Attach the slider onto the top of the seat post
(G), fix it with one seat knob (G-1) and one
flat washer (G-2).
