TOORX BRX60 - Parts List

3
PARTS LIST
NO. DESCRIPTION Q’TY NO. DESCRIPTION Q’TY
1 MAIN FRAME 1 34 PEDAL L/R 1/1
2 REAR STABILIZER 1 35 CURVE WASHER Φ8*Φ20 4
3 END CAP FOR REAR STABILIZER 2 36 ROUND END CAPS Φ25.4 2
4 CARRIAGE BOLT M10*65 4 37 END CAP FOR WIRE 1
5 FRONT STABILIZER 1 38 POWDER SPACER 1
6
END CAP FOR FRONT STABILIZER
2 39 SELF-TAPPING SCREW ST5*15 4
7 CURVE WASHER Φ10*Φ22 4 40 SELF-TAPPING SCREW ST5*15 8
8 DOMED NUT M8 4 41 CRANK L/R 1/1
9 QUICK RELEASE KNOB 1 42 BB ASSEMBLY 1
10 ALLEN SCREW M8*16 4 43 SEAT POST PLASTIC SLEEVE 1
11 SEAT 1 44 SENSOR BRACKET 1
12 FRONT POST 1 45 SPRING 1
13 TENSION KNOB +CABLE UPPER 1 46 FRENCH NUT 4
14 SENSOR WIRE MIDDLE 1 47 PULLY 1
15 SCREW M5*10 2 48 END CAP FOR CRANK 2
16
SPACER
1 49 SPACER FOR MAGNET 2
17 SQUARE WASHER 1 50 MAGNETIC ASSEMBLY 1
18 COMPUTER 1 51 HEX HEAD BOLT 1
19 HANDLE BAR 1 52 FLYWHEEL 1
20
HAND PULSE WIRE LOWER
2 53 IDLER PULLEY 1
21 CLAMP 1 54 SPRING 1
22 ALLEN SCREW M8*20 2 55 HEX HEAD NUT M8 1
23 T TYPE KNOB 1 56 HEX HEAD BOLT 1
24 SELF-TAPPING SCREW ST4*20 2 57 CHAIN COVER L/R 1/1
25 FLAT WASHER Φ4.2*Φ12*1 2 58 END CAP FOR CHAIN COVER 2
26 HAND PULSE SENSOR 2 59 HEX HEAD BOLT M6*25 1
27 FOAM GRIP FOR HANDLEBAR 2 60 HEX HEAD NUT M6 2
28 SEAT POST 1 61 SLIDING SEAT 1
29 NYLON NUT M8 5 62 CARRIAGE BOLT M8*40 1
30 SPRING WASHER Φ8 3 63 BELT 1
31 FLAT WASHER Φ8*Φ17*1.5 4 64 KNOB 1
32 TENSION CABLE LOWER 1 65 SENSOR WIRE LOWER 1
33 CLAMP COVER 1
