TOORX BRX90 - Parts List

PARTS LIST
Item Description Q’ty Item Description Q’ty
A Computer 1 F-7 C-circle 1
A-1 Pulse cable (upper) 1 G Idle 1
A-2 Motor cable 1 G-1 Nylon nut M8 5
A-3 Screw M5*10 4 G-2 Bushing Φ10*Φ14*6L 2
B Handle bar 1 G-3 Idle wheel 1
B-1 Screw M4*20 2 G-4 Flat washer 2
B-2 Pulse cable (lower) 2 G-5 Screw M8*20L 1
B-3 End cap 2 G-6 Spring 1
B-4 Foam grip 2 H Flywheel 1
B-5 Hand pulse 2 H-1 Screw 3/8″-26 5
C Handle bar post 1 H-2 Bearing 6000 1
C-1 Flat washer 1 H-3 Bearing 6300 1
C-2 Spring washer 1 H-4 One way bearing 1
C-3 Bushing 1 H-5 Bearing 6203 1
C-4 Knob 1 H-6 Small belt pulley 1
C-5 Motor cable (upper) 1 H-7 Bearing 6003 1
C-6 Handle bar cover (right) 1 H-8 Mandril of flywheel 1
C-7 Screw 4 I-L Chain cover (left) 1
C-8 Screw 2 I-R Chain cover (right) 1
C-9 Handle bar cover (left) 1 I-1 Handle bar post cover 1
D Seat post 1 I-2 Screw M4*20 5
D-1 Seat knob 1 I-3 Screw 12
D-2 Flat washer 1 I-4 Rear tube cover 1
D-3 Cap 20*40 2 J-L Crank (left) 1
D-4 Slider fixed screw 1 J-R Crank (right) 1
D-5 Slider 1 J-1 Screw M8 2
D-6 Saddle 1 J-2 Cover for crank 2
D-7 Slider cover (right) 1 K-L Pedal (left) 1
D-8 Slider cover (left) 1 K-R Pedal (right) 1
D-9 Screw 2 L Magnetic set 1
E Main frame 1 L-1 Screw M6 2
E-1 Bearing 6203 2 L-2 Spring 1
E-2 Screw M8*16L 5 L-3 Magnetic 10
E-3 Flat washer 4 L-4 Bushing 1
E-4 Motor cable (lower) 1 L-5 Wave washer 2
E-5 Plastic sleeve 1 L-6 C circle 2
8
