ASSEMBLY INSTRUCTIONS
Step 1
Assembly the rear and front stabilizer (N&M)
with 4 bolts (M-1).
Step 2
Assemble the left hand pedal (K-L) and the
right hand pedal (K-R) to the crank.
Step 3
Pass through the handlebar post (C) from
the plastic cover (I-1).
Connect the computer cable up and down
(C-5 & E-4). Fix the handlebar post to the
main frame after the above two steps.
Fasten those screws （E-2 ） and washers
(E-3&E-8) to fix the handlebar post, move
the plastic cover to right position.
4
