11
TRANSMITTER
Power Output AM: 10W/4W; FM:40W/10W/4W
Drain 8A(with modulation)
Modulation FM/AM
Unwanted Sideband 50dB
Frequency Response AM/FM: 300 to 3000Hz
Output Impedance 50ohms, unbalanced
SPECIFICATIONS
GENERAL
Frequency Range 28.000-29.695MHz(Programmable)
Frequency Band L band: A/B/C/D/E/F H band : A/B/C/D/E/F
Channel 40 channels(programmable) in each band
Frequency Control Phase-Locked-Loop Synthesizer
Frequency Tolerance ± 5.0 ppm
Temperature Range -20
℃
to +50
℃
Microphone with push-to-talk /UP/DN and coiled cord
Input Voltage 13.8V
Dimensions (in mm) 287(L)x200(W)x61(H)
Weight 1.75kg
Antenna Connector UHF, SO239
