12
Circular level
Display
window *1)
Objective lens
Sighting collimator
Optical
plummet
telescope
Horizontal
tangent screw
Horizontal
motion clamp
Leveling screw
Instrument
height mark
*1) DT-209L has one side display only.
Tribrach fixing lever
DT-205L/207L/209L
(205L/207L only)
