PRODUCT OVERVIEW
Display
DB15 Male Connector
Figure 2.1.1
Mini USB Port (For Update)
Arrow Keys
Red LED Indicator
(indicates a successful
connection)
Green LED Indicator
(indicates printing
the test report)
Compartment for
Printer Paper
Main Menu
Enter / Print
Exit
