No. Part Name Description
1 DB26 diagnostic connector
To connect with all anti-theft
cables.
2 Benz key slot To place Benz car key.
3 Key slot
To place car key for RF
defection.
4 Key chip slot To place key chip.
5 Power indicator
• Red light indicates faults.
• Orange light indicates
normal operation.
6 Valve To tighten loose EEPROM board.
7 EEPROM slot To insert EEPROM board
DB15 diagnostic connector
To connect with main diagnostic
cable.
DIY slot To insert vehicle DIY board.
Input voltage DC 12V
Input current 500 mA
Working temperature 0 to 50
℃
Storage temperature - 20 to 70
℃
Dimension 39 x 107 x 298 mm
