5.2 Installation
1) Engage technician recommended by your dealer to undertake concealed installation.
During the installation, ensure the device top side (the reception face) face upward.
Secure the device in place with our standard double-side adhesive tape.
2) Notes
Install in concealed location to prevent theft or damage.
Avoid proximity with emission source such as parking sensor, burglar alarm and other
communication devices.
There is sponge double sticky tape (special for car) as standard accessory for this product.
(It should keep the surface clean, dry and smooth. The stickiness will be better after 24
hours). Or use cable ties to secure device in place.
Device comes with GSM and GPS antennas. Please ensure reception surface faces
upward and not shielded by metallic surfaces. Suggested installation location:
- Beneath console of front wind screen;
- Around dashboard (nonmetallic coating);
- Beneath console of backwind screen.
Note: Thermal screen on windscreen may affect antenna reception causing malfunction.
Please find alternative location.
5.3 Relay Wiring Method (Model T8808-A)
1) White line connects to ACC line of car, the yellow line connects to the relay control line of
the device (yellow line).
2) There is oil pump in the oil pipe of the controlled vehicle. Cut off the Positive supply of the oil
pump. Connect the positive supply of oil pump to one of the green lines. The other end is
connected to another green line.
Note: Ensure the voltage of battery and relay compatible to prevent mal-function or damage.
You should check the battery voltage of the engine in advance.
Generally, it is 12V or 24V.
5.4 Cautions of Device Wiring - Power Supply Line
(Please refer to the Connection Diagram in the first page.)
1) Standard voltage supply of this device is 6V-36VDC. Please use factory supply lines.
The red line is positive power supply, the black line is negative power supply.
2) Orange line (ACC) connects to ON/OFF switch of vehicle ACC will enable service platform
to access the exact status of ignition switch of the vehicle.
3) The fuel cut off line (yellow line) connects to the yellow line on the fuel cut off line of relay.
Secure relay to a dry place using a cable tie. It is also advisable to protect the relay with a
plastic bag. (Model T8808-A)
