TopflyTech TLW2-12BL - Page 5

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 5
Parallel GNSS
GPS+Glonass or GPS+Beidou
Receiver type:
33 tracking / 99 acquisitions- channel GNSS
receiver
Sensitivity
Acquisition: -149 dBm
Tracking: -167 dBm
Reacquisition: -161 dBm
Horizontal Position Accuracy
Autonomous: < 2.5 m CEP
TTFF @ -130 dBm with (without) EASY™
Cold Start: < 15s (32s)
Warm Start: < 8s (28s)
Hot Start: < 1s (1s)
Interfaces
Digital Input
3 digital inputs:
1 digital input for ignition detection
1 digital input for standard or SOS
1 digital input for standard or RPM
Digital Output
2 digital outputs:
1 digital output for relay control
1 digital output for others
Configurable Input
3 configurable inputs
(Input range 0-32V)
Network, GNSS Antenna
Internal only
Indicator LED
Network and GNSS
FOTA
Yes
Temperature Sensor
1 temperature sensor
BLE 5.0
Yes
Tracker Configuring
Micro USB connector
General Specifications
Waterproof
IP65
Dimensions
120mm*42mm*12mm (4.72” *1.65” *0.47”)
Weight
49g (1.73oz)
Battery
Li-Polymer 200 mAh/ 3.7V
Operating Voltage
7V to 60V DC
Operating Temperature
-25℃ ~ +70℃ (-13°F ~ 158°F)
Storage Temperature
-40℃ ~ +85℃ (-40°F ~ 185°F)
Air Interface Protocol
Transmit Protocol
TCP, UDP, MQTT, SMS
Protocol Check & Encryption Support
MD5/ AES256
BLE Accessory Support
Yes
Scheduled Timing/angle/distance Report
Report position and status at preset intervals
External Power Status Alarm
Report when external power is disconnected
Low Power Alarm
Report when backup battery is low
Speeding Alarm
Report when speed exceed the pre-set value
Towing Alarm
From internal 6-axis accelerometer
