Club Antenna Operation
The club antenna is the center of club system operation, and it is very straight forward to use
by reading the LED light on top of the panel. Club antenna based on powerful logical
controller that provides all-in-one features and also intelligent workflow process in the club
operation. The I/O ports provide club antenna standalone operation capability without any
additional router. There are 2 mini-DIN, GPS, standard parallel port printer, and USB
Virtual COM port (VCP) to connect all devices necessary for club operations.
When you connect to iPigeon clock with the MiniDIN cable, it will also provide the power to
iPigeon clock. The printer port is standard parallel port which support LPT IEEE1284
standard printer and the default printing size is A4. The external GPS module is an optional
device which you can purchase from your local agent or TOPigeon.
