3000 Series
14
Model
Specification
3203AR
3203DR
3302AR
3302DR
3303AR
3303DR
3601AR
3601DR
3306DR 603DR 33010DR
Output Voltage 0-20V 0-30V 0-30V 0-60V 0-30V 0-60V 0-30V
Output Current 0-3A 0-2A 0-3A 0-1A 0-6A 0-3A 0-10A
CONSTANT VOLTAGE CHARACTERISTICS
Load Regulation
± 0.01% +2mV
Line Regulation
± 0.01% +2mV
Ripple & Noise (≦ 100W) ≦ 1mVrms
Ripple & Noise (≧ 100W) ≦ 2mVrms
CONSTANT CURRENT CHARACTERISTICS
Load Regulation (≦ 100W) ≦ 10mA
Load Regulation (≧ 100W) ≦ 15mA
Line Regulation
± 0.01% +2mA
Ripple & Noise (≦ 100W) ≦ 1mArms
Ripple & Noise (≧ 100W) ≦ 3mArms
DISPLAY ACCURACY
Analog Display (A)
Digital Display (D)
Full-scale 3%
≦ 0.1% +2d
PROGRAMMING SPEED
Rise Time (No Load)
(Load)
≦ 100mS
≦ 200mS (<6A), ≦ 500mS (<10A), ≦ 1S (≧ 10A)
Fall Time (No Load)
(Load)
≦ 2.5S
≦ 250mS
OUTPUT IMPEDANCE
<2mΩ + 2μ H
RECOVERY TIME
≦ 100μ S to within 0.1% of set voltage (50% to 100% load change)
FUNCTIONS
Serial Connection
Different models can be connected in series (≦ 240V)
Parallel Connection
Same models can be connected in parallel (≦ 24A)
Master - Slave Yes
REMOTE CONTROL
Voltage Programmable
By External DC Voltage
By External Resistance
0 to 10V, Control 0 to voltage setting
0 to 10KΩ , Control 0 to maximum voltage
Current Programmable
By External DC Voltage
By External Resistance
0 to 10V, Control 0 to current setting
0 to 10KΩ , Control 0 to maximum current
VOLTAGE/CURRENT READBACK AVAILABLE
Voltage Readback 0 to 10V for full-scale voltage
Current Readback 0 to 0.3V for full-scale current
OUTPUT ON/OFF CONTROL YES
REMOTE SENSING Compensate voltage drop Up to 2VDC
