3000 Series
1
1. Overview
This 3000 Series Direct Current (DC) Power Supply Operation Manual contains an introduction to the
power supply, a description of its functions, the operation procedure, the scope of application and the
specifications. The models are the 3203A, 3203AR, 3203D, 3203DR, 3302A, 3302AR, 3302D,
3302DR, 3303A, 3303AR, 3303D, 3303DR, 3601A, 3601AR, 3601D, 3601DR, 3306D, 3306DR,
3603D, 3603DR, 33010D and 33010DR.
1.1 Introduction
The 3000 Series is a single-channel-output DC power supply with the following features:
• Constant voltage and constant current output
• Short circuit and external input protection
• Allows serial or parallel connection with the same power supply model
Special Functions on Remote Models
The following functions are available only on the remote models 3203AR, 3203DR, 3302AR,
3302DR, 3303AR, 3303DR, 3601AR, 3601DR, 3306DR, 3603DR and 33010DR:
• Output voltage readback
• Output current readback
• Remote or manual-controlled ON/OFF without using the power switch
• Control of output voltage and current using external voltage and resistor
• Remote sensing
1.2 Unpacking and Checking
Unpack and check that you have the following items:
• One power cable
• This Operation Manual
• Remote-Control Operation Manual (remote models only)
• One ACS-002 banana clip
• Two phone jacks (remote models only)
• Two 9-pin RS-232C connectors (remote models only)
