Topward 3203A - 5 Specifications

3000 Series
13
5. Specifications
Model
Specification
3203A
3203D
3302A
3302D
3303A
3303D
3601A
3601D
3306D 3603D 33010D
Output Voltage 0-20V 0-30V 0-30V 0-60V 0-30V 0-60V 0-30V
Output Current 0-3A 0-2A 0-3A 0-1A 0-6A 0-3A 0-10A
CONSTANT VOLTAGE CHARACTERISTICS
Load Regulation
± 0.01% +2mV
Line Regulation
± 0.01% +2mV
Ripple & Noise (≦ 100W) ≦ 0.5mVrms
Ripple & Noise (≧ 100W) ≦ 1mVrms
CONSTANT CURRENT CHARACTERISTICS
Load Regulation (≦ 100W) ≦ 10mA
Load Regulation (≧ 100W) ≦ 15mA
Line Regulation
± 0.01% +2mA
Ripple & Noise (≦ 100W) ≦ 1mArms
Ripple & Noise (≧ 100W) ≦ 3mArms
DISPLAY ACCURACY
Analog Display (A)
Digital Display (D)
Full-scale 3%
≦ 0.1% +2d
PROGRAMMING SPEED
Rise Time (No Load)
(Load)
≦ 100mS
≦ 200mS (<6A), ≦ 500mS (<10A), ≦ 1S (≧ 10A)
Fall Time (No Load)
(Load)
≦ 2.5S
≦ 250mS
OUTPUT IMPEDANCE
< 2mΩ + 2μ H
RECOVERY TIME
≦ 100μ S to within 0.1% of set voltage (50% to 100% load change)
FUNCTIONS
Series Connection
Different models can be connected in series (≦ 240V)
Parallel Connection
Same models can be connected in parallel (≦ 24 A)
Master - Slave N/A
POWER SOURCE
ACV 100/120/220/240 ±10%, 50/60Hz
ACCESSORIES ACS-002 X1
DIMENSIONS
W X H X D (mm)
120 X 160 X 200 230 X 160 X 324 230 X 160
X 366
