3000 Series
5
(1) Power Switch: Power ON/OFF switch (1=ON, 0 = OFF)
(2) Output ON/OFF LED: Red LED for indicating output ON or OFF
(3) Output ON/OFF Switch: Output ON/OFF control switch (only available in remote models)
(4) -S Remote Sensing Input Terminal: For sensing output voltage at the - load terminal (only
available in remote models)
(5) Output Current Adjustment Knob: For adjusting output current at constant current (C.C.
Mode)
(6) - Output Terminal: Negative output terminal (black)
(7) + Output Terminal: Positive output terminal (red)
(8) Voltage Indicator
a) Analog: As indicated by the pointer on the 40x40mm (Class 2.5) meter
b) Digital: Displayed in full 3-digit red 0.52" LED
(9) C.V. Mode LED: Green LED to indicate constant voltage
(10) C.C. Mode LED: Red LED to indicate constant current
(11) Current Indicator
a) Analog: As indicated by the pointer on the 40x40mm (Class 2.5) meter
b) Digital: Displayed in full 3-digit red 0.52" LED
(12) Coarse Output Voltage Adjustment Knob: For adjusting output voltage at constant voltage
(C.V. mode)
(13) GND Terminal : Ground terminal (green)
(14) +S Remote Sensing Input Terminal: For sensing output voltage at the + load terminal (only
available in remote models)
(15) Fine Output Voltage Adjustment Knob: For fine adjustment of output voltage at constant
voltage (C.V. mode)
(16) Warning Label: The bare parts of the output terminals and fittings are electrical sensing parts.
Do not touch these parts during use.
