Toradex Colibri Migration Guide
Toradex AG l Altsagenstrasse 5 l 6048 Horw l Switzerland l +41 41 500 48 00 l www.toradex.com l info@toradex.com
Page | 2
Revision history
Date
Doc. Rev.
Changes
23-Oct-07
Rev. 1.0
Initial release.
Supported modules:
Colibri PXA270 V1.0 / V1.2
Colibri PXA320 V1.2
Colibri PXA300 V1.0
26-Oct-07
Rev. 1.1
Description for Data[31:16] on PXA270 module added.
Supported modules:
Colibri PXA270 V1.0 / V1.2
Colibri PXA320 V1.2
Colibri PXA300 V1.1
13-Dec-07
Rev. 1.2
CAN description for Orchid removed (there is no CAN on the Orchid)
Supported modules:
Colibri PXA270 V1.0 / V1.2
Colibri PXA320 V1.2
Colibri PXA300 V1.1
12-Sept-08
Rev. 1.3
PXA310 data added (in general it is equal to PXA300)
PXA320: changed pin names from -> to (these pins have no GPIO functionality)
GPIO56 -> CIF_DD<7>
GPIO59 -> CIF_MCLK
GPIO60 -> CIF_PCLK
GPIO61 -> CIF_HSYNC
GPIO62 -> CIF_VSYNC
29-Okt-08
Rev. 1.4
SODIMM Pin 99 can’t be used as GPIO on Colibri PXA3xx modules.
Added a note regarding second instance of GPIOs.
31-Dec-08
Rev. 1.5
SODIMM Pin 184 can’t be used as GPIO on Colibri PXA300 and PXA310 modules
Minor changes to clarify several descriptions.
17-Feb-09
Rev. 1.6
Added PS2 description (Mouse and Keyboard)
24-Sep-09
Rev. 1.7
Added notes 12 and 13 to compatibility list (SODIMM Pin 88,90,92)
22-Jan-10
Rev. 1.8
Removed broken www link to EvalBoard schematic.
PXA310 GPIO97 and GPIO98 have pull-up and pull-down description (Note 14 Compatibility List)
04-Jun-10
Rev. 1.9
Spelling correction
Added different analog input voltage range description (Chapter 2.7 section 10).
10-Jun-10
Rev. 2.0
Added clarification to chapter 2.7 section 10.
02-Sep-10
Rev. 2.1
Add first preliminary information for the Colibri T20
06-Sep-10
Rev. 2.1
Added details for Colibri PXA270 V2.2 and Colibri PXA320 V2.0 modules (Chapter 3, notes 10 and 11)
27-Dec-10
Rev. 2.2
Add information about Colibri T20 address signals (Chapter 3, note 24)
Add information about USB 2.0 high speed to Chapter 2.3, 2.4 and 2.5
Change name Colibri Tegra T20 -> Colibri T20
11-Dec-12
Rev. 2.3
Add information about Colibri T30
Change name of Colibri T20 to Colibri T20
Update links
Add information about Evalboard V3.1
