Toradex Colibri Migration Guide
Toradex AG l Altsagenstrasse 5 l 6048 Horw l Switzerland l +41 41 500 48 00 l www.toradex.com l info@toradex.com
2.6 Protea V1.1
For Colibri PXA270:
Set the Jumper JP2 (next to the Ethernet connector and battery socket) to 1-2.
For Colibri PXA3x0 and Colibri T20/T30:
Set the Jumper JP2 to 2-3.
The USB interfaces on the Evaluation board are not USB 2.0 high speed compatible. For more information see: http://developer.toradex.com/knowledge-base/usb-2.0-high-speed-(480mbps)
Insert the Colibri module into the Protea and power the device. The WinCE will start up and all interfaces will work (except CAN and RS485/422 because this drivers aren’t included in the Toradex standard WinCE image).
