TU-2 Series Wrench

ITEM

NAME PART # QTY. ITEM NAME PART # QTY. ITEM NAME PART # QTY.

1 Housing TU-2-01 1 14 Square Drive TU-2-11-1 1 28 Piston Seal TU-2-33 1

2 Reaction Arm TU-2-03-1 1 15 Sq. Dr. Locking Pin TU-2-11-2 1 31 Gland Seal TU-2-35 1

3 Spline Sleeve TU-2-03-2 1 16 Sq. Drive Pin TU-2-11-3 1 32 End Plug Seal TU-2-37 1

4 Locking Pin TU-2-03-3 1 18 Sq. Drive Sleeve TU-2-13 2 35 Cylinder Ring TU-2-43 1

5 Retract Button TU-2-03-4 1 19 End Plug TU-2-15 1 36 Sleeve O-ring TU-2-51 2

6 Reaction Arm Screw TU-2-03-5 1 20 Piston Rod Assembly TU-2-17 1 39 Swivel Set

STU-4M-4M

7 Reaction Arm Spring TU-2-03-6 1 22 Roll Pin TU-2-19 1 40 Coupler Set HC-S-100 1

8 Reaction Arm Cover TU-2-03-7 1 23 Cylinder Gland TU-2-21 1

9 Cover Screws TU-2-03-8 2 24 Shroud TU-2-23 1 50 Gland Wrench TU-2-GW

11 Ratchet TU-2-05 1 25 Shroud Screws TU-2-25 2

12 Drive Segment TU-2-07 1 26 Drive Segment Spring TU-2-27 2 Reaction Arm Assembly TU-2-03

13 Drive Plate TU-2-09 1 27 Rod Seal TU-2-31 1 Square Drive Assembly TU-2-11
