Torin T93007 - Page 13

13
Ref.
Part# Description
Qty
T93007 T95007 T93007 T95007
1 Top cast nut 1
2 O-ring D71x5.3G O-ring D85x5.3G 1
3
Rectangular ring
D111x102x1.2mm
Rectangular ring
D165.5x161x6mm
1
4 Reservoir 1
5 TF1201C-29 TF1201C-29 Oil plug 1
6 T-ring 1
7 QYL50D-25(ASM) QYL50D-25(ASM) Release valve assembly 1
8 GB308-8 GB308-8 Steel ball Ø8mm 1
9 Pump base 1
10 Oil lter pipe 1
11 Steel ball retainer 1
12
Cylinder ring
D87.5x81x2.6mm
Cylinder ring
D107.5x96x4mm
1
13 Cylinder 1
14 O-ring D64X5.3G O-Ring D79x5.3G 1
15 Bowl washer 1
16 Piston rod assembly 1
17 GB5780-M6x30 GB5780-M6x30 Hex head bolt M6x30mm 2
18 TF0602.1-1(ASM) T93204.1(ASM) Handle assembly 1
19 Handle socket 1
20 QYL8-22A(ASM) QYL8-22A(ASM) Roundwire snap ring Ø1.2x18mm 3
21 Connecting bar 1
22 GB882-8x35 GB882-8x35 Pin Ø8x35mm 3
23 QYL20-26(ASM) QYL20-26(ASM) Pump plunger assembly 1
24 J-dust-ring 1
25 Pump 1
26 Steel washer D22x10x1mm 1
27 GB308-6 GB308-6 Steel ball Ø6mm 2
28 T93007.MF T95007.MF Seal kit 1
