19
TRACTION DRIVE ASSEMBLY
1 1 19283 Weldment, Chassis Frame
2 2 18079 Caster
3 8 03301 Washer, Plain 5/l6"
4 8 01577 Lockwasher 5/16"
5 8 18111 Screw
7 2 03536 Lock washer 3/8"
8 2 18104 Screw
9 2 03321 Washer, Plain 3/8"
10 2 18509 Wheel w/Set Screw
11 1 19258 Transaxle
14 2 18115 Key
15 4 16031 SCREW-HEX HD CAP 5/16-18 X 1-1/2 (ZP)
16 4 01574 Lock washer, ¼” (H/S)
17 4 05427 Screw, Rd. Hd. ¼” 20 x 5/8”
18 2 19294 Retainer, EZ Transaxle
20 4 02956 #8 - 32 Lock Nut
21 4 10892 #8 - 1/2" Lock Screw
22 4 18309 5/8" Dia. Cable Clamp
23 2 03960 Washer-Plain 25/32 ID (ZP)
*
*
2
2
24422
24423
Brush, Carbon (Transaxle)
Cap, Brush (Transaxle)
* Not Shown (Service Only Items)
Item No. Qty. Part No. Description
