g206686
Figure2
1.Rightrearbracket
9.Screw(5x16mm)
2.Washer(5mm)
10.Rearlight
3.Locknut(5mm)11.Reector
4.Washer(8mm)
12.Numberplate
5.Springwasher(8mm)
13.Number-platelamp
6.Screw(8mm)14.Self-tappingscrew(6x16mm)
7.Indicatorbulb
15.Leftrearbracket
8.Sidebulb
InstallingtheNumber-Plate
Assembly
1.Drill4holes(5mmdiameter)intheframe;referto
Figure2andFigure3.Usethenumberplateasa
template.
2.Securethebracketusingtheself-tappingscrews(Figure
2).
3.Connectthewiretothelamp.
4.Securethewiretotheuprightsectionoftheframe
usingthe3cableties(1cabletietosecureatthetop
ofthewireassemblyfromthelamp,asecondcable
tietothecentersecuringwirebehindthebracketand
thethirdcabletietoretainthewireandsleeveatthe
bottomoftheupright).
5.Locatethe3-pinsocketthroughtheapertureinthe
rearchassisandconnectthenumberplatewire.
Note:Youcanremovetherearguardplateforaccess.
