Measurements
Wheel tread width 54-1/2 in. (138 cm)
Wheel base 55 in. (140 cm)
Width 76-1/2 in. (194 cm)
Transport width
RM 2300-D
RM 2600-D
72 in. (183 cm)
85 in. (216 cm)
Length
Height
Weight
Model 03422—2WD
without cutting units
1066 lb. (484 kg)
Model 03427—3WD
without cutting units
1096 lb. (497 kg)
Model 03461—27″ 5
blade cutting unit
136 lb. (62 kg)
Model 03462—27″ 8
blade cutting unit
143 lb. (65 kg)
Model 03466—32″ 5
blade cutting unit
158 lb. (72 kg)
Model 03467—32″ 8
blade cutting unit
167 lb. (76 kg)
Optional Equipment
Cushion Seat Model No. 30796
Deluxe Seat w/Suspension Model No. 30797
Armrest Kit for Model No. 30796 Model No. 30707
Seat Weight Kit
(for Seat Model No. 30796 Only)
Part No. 80-4210
3WD Rear Weight Kit Part No. 94-3663
Rear Weight Kit Part No. 83-9370
Rear Weight Part No. 83-9390
RM 2300-D Optional Equipment
5 Blade Cutting Unit Model No. 03461
8 Blade Cutting Unit Model No. 03462
2WD Weight Kit (Baskets) Part No. 94-5974
RM 2600-D Optional Equipment
5 Blade Cutting Unit Model No. 03466
8 Blade Cutting Unit Model No. 03467
Setup
Note: Determine the left and right sides of the machine from the normal operating position.
Loose Parts
Note: Use this chart as a checklist to ensure that all parts necessary for assembly have been received. Without these parts,
total setup cannot be completed. Some parts may have already been assembled at the factory.
Description
Qty. Use
Wheel assembly
Flat washer
Axle
Locknut
1
2
1
1
Installing the rear wheel on Model No. 03422
Wheel assembly
Lub nut
1
4
Installing the rear wheel on Model No. 03427
Flat washer
Capscrew
Locknut
3
3
3
Mounting the carrier frames to the cutting units.
To Next Page
