SpecialTools
YoucanorderthesespecialtoolsfromyourT oroDistributor.Sometoolsare
alsoavailablefromalocaltoolsupplier.
HydraulicPressureTestingKit
ToroPartNo.TOR47009
Usethiskittotakevariouspressurereadingsfordiagnostic
tests.Quickdisconnectttingsareprovidedtoattachdirectly
tothematingttingsonthemachinetestportswithoutthe
tools.Ahigh-pressurehoseisgivenforremotereadings.
Contains1each:6,900kPa(1,000psi),34,500kPa(5,000
psi),and69,000kPa(10,000psi)gauges;refertoTestingthe
HydraulicSystem(page6–56).
15GPMHydraulicTesterKit(PressureandFlow)
ToroPartNo.TOR214678
Usethistestertotestthehydrauliccircuitsandcomponents
forowandpressurecapacitiesasrecommendedinT esting
theHydraulicSystem(page6–56).Thistesterincludesthe
following:
InletHose–Thishoseconnectsthesystemcircuittotheinlet
sideofthehydraulictester.
LoadValve–Turnthevalvetorestricttheowtocreatea
simulatedworkingloadinthecircuit.
PressureGauge–Aglycerinelledpressuregauge0to
34,500kPa(0to5,000psi)toprovideoperatingcircuit
pressure.
FlowMeter–Thismetermeasurestheactualuidowinthe
operatingcircuitwithagaugeratedat5to55L/minute(1
to15gallons/minute).
OutletHose–Ahosefromtheoutletsideofthehydraulic
testerthatconnectstothehydraulicsystemcircuit.
Fittings–Anassortmentofhydraulicttingsareincluded
withthiskit.
HydraulicSystem:SpecialTools
Page6–44
Reelmaster
®
5410/5510/5610Series
15216SLRevC
