ServicingtheSteeringCylinder

g217166

Figure190

1.Barrel

6.O-ring

11.Head

2.Locknut

7.O-ring

12.Retainingring

3.Piston8.Back-upring

13.BSseal

4.Wearring9.Dustseal

5.BPseal

10.Shaft

DisassemblingtheSteeringCylinder

1.Slowlypumpthecylindershafttoremovethehydraulicuidfromthesteering

cylinderintoadrainpan.Plugboththeportsandcleantheoutersurfaceof

thecylinder.

IMPORTANT

Whenyouclampthesteeringcylinderinavise,clampthebarrel

clevisonlytopreventdamage.Donotclosetheviseonthebarrel.

2.Mountthesteeringcylindersecurelyinavisebyclampingonthebarrel

clevis.Useaviseequippedwithsoftjaws.

3.Useaspannerwrench,rotatetheheadclockwiseuntiltheedgeofthe

retainingringappearsinthebarrelopening.Insertascrewdriverunderthe

HydraulicSystem:ServiceandRepairs

Page6–230

Reelmaster

5410/5510/5610Series

15216SLRevC
