15.
Remove
and
retain
all
engine
output
shaft
hardware
(
Figure
7
).
Note:
Y
ou
may
discard
the
set
screws.
g274554
Figure
7
1.
Gearbox
4.
W
asher
7.
Gearbox
gasket
2.
Bolt
5.
Engine
gear
8.
Set
screw
3.
Lock
washer
6.
Engine
adapter
9.
Engine
16.
Clean
the
frame
and
check
for
damage
or
wear
.
17.
Check
the
gearbox
gasket
for
damage
or
wear;
replace
the
gasket
if
it
is
damaged.
6
5
7
Table of Contents
Table of Contents
1
Introduction
1
Safety
2
Safety and Instructional Decals
2
Installation
4
Installing a Gearbox Vent
4
Removing the Existing Engine
4
Installing the New Engine
7
Preparing the New Engine
8
Installing the Controls
9
Installing the Wire Harness and Throttle Cable
11
Lubricating and Adjusting the Machine
14
Product Overview
14
Controls
14
Operation
15
Fuel Specifications
15
Using Stabilizer/Conditioner
15
Filling the Fuel Tank
15
Opening and Closing the Fuel-Shut-Off Valve
16
Maintenance
17
Recommended Maintenance Schedule(S)
17
Preparing the Machine for Maintenance
17
Servicing the Engine Oil
18
Servicing the Air Cleaner
19
Servicing the Spark Plug
20
