1
InstallingtheRollBar
Partsneededforthisprocedure:
1Rollbar
4
Bolt(1/2x3-3/4inches)
4
Flange-nut(1/2inch)
Procedure
1.Removethetopcratesupportfromthecrate.
2.Removetherollbarfromthecrate.
3.Installtherollbarintothepocketsoneachsideof
themachine,using4bolts(1/2x3-3/4inches)and4
ange-nuts(1/2inch)(Figure3).
g014601
1
2
3
Figure3
1.Rollbar
3.Flange-nut(1/2inch)
2.Bolt(1/2x3-3/4inches)
4.Torquethefastenersto136to149N-m(100to110
ft-lb).
2
InstallingtheSeat
Partsneededforthisprocedure:
1
Seat
1
Seatwiringharness
Procedure
Note:Mounttheseatinthefrontsetofmountingholesto
gainanadditional7.6cm(3inches)intheforwardadjustment,
orintherearmountingholesforanadditional7.6cm(3
inches)intherearwardadjustment.
1.Removeanddiscardthelagboltssecuringtheseat
slidesandcuttheshippingstraps.
2.Removethe4bolts(5/16x3/4inch)andwashers
fromtheshippingbracketanddiscardthebracket.
3.Securetheseattotheseatbasewith4boltsandwashers
removedpreviously(Figure4).
Figure4
1.Seat
3.Washer
2.Seatbase4.Bolt(5/16x3/4inch)
4.Locatetheopenconnectoronthemainwiringharness
totherightoftheseatandconnectittothewiring
harnessthatcamewiththeseat.
5.Routetheseatwiringharnessaroundtheseatslides,
ensuringthatitwillnotbepinchedwhentheseat
moves,andconnectittotheportonthebottomof
theseat.
13
