InstallingtheBatteries
Partsneededforthisprocedure:
2Batteryholddown
2Batteryhold-downrod
7
Batterycables
4Battery-traypads
1Batterypad
2
Flangenut(3/8inch)
1Battery-terminal-protectorspray
Procedure
UseeitherTrojanT105orT145,orUSBatteryUS2200or
US145.
BatterySpecication:6V225AH@20hrrate
Dimensions:(LxWxH)26.4x18.1x26.5cm(10-3/8x
7-1/8x10-7/16inches)
1.TurnthekeyswitchtotheOffpositionandremove
thekey.
2.Installthebattery-traypadsintotherear-frame
assembly(Figure4).
Figure4
1.Battery-traypads
2.Rear-frameassembly
3.Removetheadhesivestripfromthebackofthebattery
padandinstallitontothefrontinsidefaceoftherear
frame(Figure5).
Note:Thepadshouldbeapproximately6mm(1/4
inch)belowthebottomedgeoftheuppersetofcutout
holes(Figure5).
Figure5
1.Batterypad3.Uppercutoutholes
2.Frontinsideface
4.Installthebatteries(Figure6).
Note:Payattentiontothebatterypolaritywhen
installingthenewbatteries(Figure6).
WARNING
Incorrectbatterycableroutingcoulddamage
themachineandcables,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
Alwaysensurethebatterypolaritywhen
makingconnections.
CAUTION
Batteriescangiveyouapowerfulelectrical
shock.
•Usetoolswithplastichandlesorwrapthe
handlesofmetaltoolswithelectricaltape.
•Becarefulnottocontactbothapositive
terminalandanegativeterminalatthe
sametime.
12
