GreasingtheNailDrag
Beforeoperatingthenaildrag,greaseit;referto
LubricatingtheMachine(page6).
Important:Failuretoproperlygreasetheunitwill
resultinprematurefailureofcriticalparts.
Operation
OperatingtheNailDrag
•Theamountthedragnailsengageintheground
determinesthescarifyingdepth.
•T oadjusttheamountthenailsengageinthe
groundproceedasfollows:
1.Removethelynchpinsfromtheclevispins
(Figure5).
g006213
Figure5
2.Pressdownontheplatestoincreasethe
scarifyingdepthorreleasetheplatesto
decreasethescarifyingdepth.Eachhole
changesthenailengagement9/16inch(14
mm).
3.Installthelynchpinsintothedesiredclevis
pinholes;ensurethatallthelynchpinsare
setatthesamedepth.
