Toro 08761 User Manual

1
InstallingtheSteering
Wheel
Partsneededforthisprocedure:
1
Steeringwheel
1Foamcollar
1Washer
1Locknut
1
Steering-wheelcover
Procedure
1.Movethefrontwheelsothatitpointsstraight
ahead.
2.Slidethefoamcollar,smallendrst,ontothe
steeringshaft(Figure3).
g025723
Figure3
1.Foamcollar4.Nut
2.Steeringwheel5.Steering-wheelcover
3.Washer
3.Slidethesteeringwheelontothesteeringshaft
(Figure3).
4.Securethesteeringwheeltothesteeringshaft
withawasherandalocknut(Figure3).
5.Torquethelocknutto27to35N∙m(20to26
ft-lb).
6.Pressthesteering-wheelcoverintopositionon
thesteeringwheel(Figure3).
2
RemovingtheBattery
NoPartsRequired
Procedure
Removethe2wingnutsandwasherssecuringthe
topbatteryhold-downtothesidebatteryhold-downs
(Figure4).Removethetopbatteryhold-downand
removethebattery.
g002701
Figure4
1.Battery
3.Negative(-)battery
terminal
2.Positive(+)battery
terminal
4.Topbatteryhold-down
8
