Toro 20355 - Adjusting the Self-Propel Drive

AdjustingtheSelf-Propel
Drive
Wheneveryouinstallanewself-propelcableorif
theself-propeldriveisoutofadjustment,adjustthe
self-propeldrive.
1.Turntheadjustmentknobcounterclockwiseto
loosenthecableadjustment(Figure30).
g208188
Figure30
1.Self-propel-drivecables
4.Turntheknobclockwiseto
tightentheadjustment.
2.Handle(leftside)
5.Turntheknob
counterclockwiseto
loosentheadjustment.
3.Adjustmentknob
2.Adjustthetensiononthecables(Figure30)by
pullingthembackorpushingthemforwardand
holdingtheminthatposition.
Note:Pushthecablestowardtheengineto
increasethetraction;pullthecablesawayfrom
theenginetodecreasethetraction.
3.Turntheadjustmentknobclockwisetotighten
theadjustmentofthecables.
Note:Bothofthecablesshouldextend38mm
(1.5inches)pasttheclampswhenthehandleis
alignedwiththerstmarkontheguide;refer
toFigure31.
g209518
Figure31
1.38mm(1.5inches)
3.Firstmark
2.Guide
4.Handle
22
