Toro 20372 - Initial Setup and Assembly; Handle Assembly and Adjustment

Setup
Important:Removeanddiscardtheprotective
plasticsheetthatcoverstheengineandanyother
plasticorwrappingonthemachine.
Important:Topreventaccidentalstarting,
donotinserttheelectric-startbuttonintothe
electric-startignitionuntilyouarereadytostart
theengine(electric-startmodelonly).
1
AssemblingandUnfolding
theHandle
NoPartsRequired
Procedure
1.Removeandsavethe2handleknobsand2
carriageboltsfromthehandlebrackets(Figure
4).
g032865
Figure4
1.Handleknob(2)2.Carriagebolt(2)
2.Installthehandleendsontothemowerhousing
sothatthepinattachedtoeachhandlebracket
isinthelowerholeofitsrelatedhandleend
(Figure5).
g032866
Figure5
1.Pin2.Handleend
Note:Thepinsdonotshowthroughtheholes
inthehandleendswhenthehandleisinthe
foldedposition.
3.Unfoldthehandletotheoperatingpositionby
rotatingitrearward(Figure6).
g032868
Figure6
1.Operatingposition
2.Foldedposition
4.Insertthecarriagebolt(withtheboltheadtoward
theinside)throughtheupperorlowersquare
holeinhandlebracketandtheupperholeinthe
handleend(Figure7).
6
