Toro 22155 - Mower Setup Procedures; Loose Parts Verification; Handle Installation

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Oval-headbolt(5/16x1-1/2inches)
2
Bolt(5/16x1-1/2inches)
2
Spacer
2
Locknut(5/16inch)
4
1
Cabletie
1
Installthehandle.
2
SAE30WdetergentoilwithanAPI
serviceclassicationofSH,SJ,SL,or
higher(notsuppliedwiththemower).
20oz.
(0.55l)
Filltheenginewithoil.
3
Nopartsrequired
–
Installtherecycleplugorgrassbag.
1
InstallingtheHandle
Partsneededforthisprocedure:
2
Oval-headbolt(5/16x1-1/2inches)
2
Bolt(5/16x1-1/2inches)
2
Spacer
4
Locknut(5/16inch)
1
Cabletie
Procedure
1.Removethetwoscrewsthatholdthebackcoverin
placeandremovethebackcover(Figure3).
Figure3
2.Attachthehandletothemowerhousing(Figure4)
usingthe4bolts,4locknuts,and2spacersinthe
loosepartsbag.
Figure4
1.Oval-headbolt(5/16x
1-1/2inches)(2)
3.Spacer(2)
2.Bolt(5/16x1-1/2inches)
(2)
4.Locknut(5/16inch)(4)
6
