Measurements
Length 208 cm (82 in.)
Width (Rear Wheels) 119.4 cm (47 in.)
Height 127 cm (50 in.)
Weight 442 kg (1185 lb.)
Optional Equipment
52” Side Discharge Cutting Unit Model No. 30555
52” Rear Discharge Cutting Unit Model No. 30568
62” Side Discharge Cutting Unit Model No. 30551
62” Guardian Recycler Cutting Unit Model No. 30569
72” Side Discharge Cutting Unit Model No. 30553
48” V-Plow Kit Model No. 30750
V-Plow Mounting Kit Model No. 30749*
Arm Rest Kit Model No. 30707
Rear Discharge Shield Kit Model No. 30578
Rear Weight Box Kit Part No. 24-5780
Grass Collection System Model No. 30502**
Wide Tires w/rim
23 x 10.5-12, 4 ply Part No. 62-7020
23 x 10.5-12, 6 ply Part No. 69-9870
Wheel Weights-50 lbs. (23kg.) Part No. 11-0440
Rear Weight Kit—70 lbs. (32 kg.) Part No. 24-5780
Weight Kit—20 lbs. Part No. 92-8763
Tire Chains (Front) Part No. 11-0390
Standard Seat Kit Model No. 30624
Deluxe Seat Kit Model No. 30625
*Required with 30750 V-plow. Tire chains, part no.
11-0390 recommended.
** 52” Blower Kit (for Model 30555 deck) or Model
30506 62” Blower Kit (for Model 30551 deck) can be
used with either Model No. 30504, 9 cu. ft. Hopper
Kit or Model No. 30505, 15 cu. ft. Hopper Kit.
13
Power take-off drive The power take-off shaft is clutched by a belt directly from the engine output shaft.
The power take-off shaft engaged by an electric clutch/brake assembly. Power take-
off speed—2200 RPM@3250 RPM engine speed.
Implement Connection Universal joint and telescoping shaft assembly.
Lift Cylinders Two with 2 in. (51 mm) bore, 3.5 in. (89 mm) stroke.
Interlock Switches Prevent engine starting if the traction pedal or power take-off switch are engaged.
Stops the engine if the operator leaves the seat with either the traction pedal or power
take-off switch engaged. Stops the engine if the traction pedal is engaged with parking
brake engaged.
