Specifications
Note: Specifications and design subject to change without notice.General Specifications
Engine Kubota three-cylinder, 4-cycle, liquid-cooled diesel engine. 26 hp @ 3000. Engine
governed to 3200–3250 rpm high idle, no load.
Air Cleaner Heavy-duty remote mounted.
Fuel Tank Capacity 8.5 gal. (32 l) Equipped with a fuel filter/water separator to capture water in the fuel.
Fuel Pump 12-volt electric (transistor type) w/replaceable fuel filter.
Cooling System 7 qt (6.6 l) capacity. Remote-mounted expansion tank 1 qt (0.946 l) capacity. System
contains a 50/50 mix of ethylene glycol anti-freeze and water. Front mounted air/oil
cooler used to cool hydraulic oil for the hydrostatic transmission.
Electrical 12 volt with 530 cold cranking amps at 0° F and 75-minute reserve capacity at 80° F.
Drive Coupling Transmission driven by steel shaft with flexible rubber couplings at each end.
Transmission Hydrostatic, U-type. Implement Relief Setting—700–800 psi (4,826–5,516 kPa).
Hydraulic Filter Replaceable 25-micron filter mounted directly to the transmission.
Front Axle The front axle serves as a hydraulic fluid reservoir and mates directly with the
transmission. Approximately 6 qt (5.7 l) capacity.
Rear Axle The rear axle is mchanically driven from the front axle by a universal shaft. The axle has
a be-directional overrunning clutch in the rear driveshaft. When lubricating the rear axle,
use SAE 80W-90 gear lube, API GL-5. Lubricant capacity is 2.9 liter (3.1 qt.)
Brakes Mechanical drum-type. Individually controlled by two pedals connected by cable and
conduit for steering assist. Pedals may be latched together for two wheel braking. Lever
provided for parking brake.
Tires Front Tires—23 x 8.50-12, Rear Tires—16 x 6.50-8. All tires: 4-ply rating, tubeless type.
Pressure—20 psi (138 kPa).
Ground Speed 0–16 kmh forward and reverse.
Main Frame Frame is welded, formed steel.
Instrumentation Fuel gauge, water temperature gauge, hour meter and warning lights for high temperature
shutdown, oil pressure, amperage and glow plug are mounted on the console.
Controls Throttle, power take-off switch, parking brake, implement lift, implement lift lock,
ignition switch and high temperature override switch are all hand-operated.
Forward/reverse traction pedal and turning brakes are foot-operated.
