SpeedLimiter
Ifdesired,thescrewcanbeadjusted(Figure3)tolimit
theamountthetractionpedalcanbedepressedinthe
forwarddirectiontolimitthemowingspeed.
Important:Thetractionpedalmustcontactthe
speedlimiterbeforereachingtheendofthepump
stroketopreventpumpdamage.
Figure3
1.Speedlimiter
Important:Wheninthemowposition,thespeed
limiterscrewmuststopthetractionpedalbeforethe
pumpreachesfullstrokeordamagetothepump
mayoccur.
LiftLevers
Thelevers(Figure4)raiseandlowerthecuttingunits.
CuttingUnitServiceLock
Thecuttingunitservicelock(Figure4)locksthefront
cuttingunitliftleverwhenthecuttingunitisinthe
raisedposition.
KeySwitch
Thekeyswitch(Figure4)hasthreepositions:Off,
On/Preheat,andStart.
PTOSwitch
ThePTOswitch(Figure4)hasthreepositions:On
(engage),Neutral,andOff(disengage).Carefullylift
andpushthePTOswitchforwardtotheOnposition
tostarttheimplementorcuttingunitblades.Slowly
pulltheswitchbackwardtotheOffpositiontostop
implementoperation.
Hi-LoSpeedControl
Thecontrol(Figure4)allowsthespeedrangetoincrease
fortransportofthemachine.
FlowDividerSwitch(optional)
Whenoperatinginmow(low)speed,pressandhold
owdividerswitch(Figure4)toenhancetractiondrive
performanceincompromisedoperatingconditions.
Figure4
1.Liftlever
9.Audiblealarm
2.Keyswitch10.Temperatureresetswitch
3.PTOswitch
11.Hourmeter
4.Hi-lospeedcontrol12.Fuelgauge
5.Flowdividerswitch
(optional)
13.Throttle
6.Cruisecontrol(optional)
14.Powerpoint
7.Alarmsilenceswitch15.Frontcuttingunitservice
lock
8.Fanswitch
CruiseControl(Optional)
Thecruisecontrol(Figure4)setsthespeedofthe
machine.
FuelGauge
Thefuelgauge(Figure4)indicatestheleveloffuelin
thetank.
HourMeter
Thehourmeter(Figure4)showsthetotalhoursthatthe
machinehasbeenoperated.
TemperatureOverrideSwitch
Pressandholdtheresetswitch(Figure4)tostartthe
engineafterhightemperatureshutdown.Useonlyfor
emergencyoperation.
