g011595
Figure2
1.Elastomericspider3.Pulleycoupler
2.Spiderhub
ReplacingtheFrontMower
Deck
WARNING
Theliftarmsraiseupwhenthemowerdeckis
removedandthemachineisturnedon.
Movethemowerdeckunderthemachineand
connectitbeforeturningthemachineon.
1.Removethehairpincottersandtheclevispins
securingtheheight-of-cutchainstotherearof
themowerdeck(Figure3).Retainthehardware
forinstallationonthenewmowerdeck.
g011596
Figure3
1.Height-of-cutchain2.Clevispinandhairpin
cotter
2.Removebolts,washers,andlocknutssecuring
eachlift-armmounttothecaster-armtube
(Figure4).
g011597
Figure4
1.Lift-armmount(2)
3.Movethemowerdeckawayfromthetraction
unit.
4.Movethenewmowerdeckintopositionand
mountittoeachcaster-armtubebyreversing
theprocedure.
5.Adjusttheheightofcutforthemowerdeck;refer
totheprocedureintheOperator’sManualfor
themachine.
2
