Toro 30449 - Inspecting and Sharpening the Cutter Blade(S)

2.Grasptheendofthebladeusingaragorthickly
paddedglove.Removethebladebolt,anti-scalpcup,
andbladefromthespindleshaft(Figure86).
3.Installtheblade,anti-scalpcup,andbladebolt.
Tightenthebladeboltto85to110ft-lb(115to149
N⋅m).
Important:Thecurvedpartoftheblademust
bepointingtowardtheinsideofthecuttingunit
toensurepropercutting.
Note:Afterstrikingaforeignobject,torqueallthe
spindlepulleynutsto130to150ft-lb(176to203
N⋅m).
Figure86
1.Bladebolt2.Anti-scalpcup
InspectingandSharpeningthe
CutterBlade(s)
DANGER
Awornordamagedbladecanbreak,andapiece
ofthebladecouldbethrownintotheoperator's
orbystander'sarea,resultinginseriouspersonal
injuryordeath.Tryingtorepairadamagedblade
mayresultindiscontinuedsafetycerticationof
theproduct.
•Inspectthebladeperiodicallyforwearor
damage.
•Nevertrytostraightenabladethatisbentor
weldabrokenorcrackedblade.
•Replaceawornordamagedblade.
Twoareasmustbeconsideredwhencheckingand
servicingthecutterblade-thesailandthecuttingedge.
Bothcuttingedgesandthesail,whichistheturned
upportionoppositethecuttingedge,contributetoa
goodquality-of-cut.Thesailisimportantbecauseit
liftsthegrassupstraight,therebyproducinganeven
cut.However,thesailwillgraduallyweardownduring
operation,andthisconditionisnormal.Asthesail
wearsdown,thequality-of-cutwilldegradesomewhat,
althoughthecuttingedgesaresharp.Thecuttingedge
oftheblademustbesharpsothatthegrassiscutrather
thantorn.Adullcuttingedgeisevidentwhenthetips
ofthegrassappearbrownandshredded.Sharpenthe
cuttingedgestocorrectthiscondition.
1.Positionthemachineonalevelsurface.Raisethe
cuttingunit,engagetheparkingbrake,putthe
tractionpedalinneutral,putthePTOleverin
theOffposition,stoptheengine,andremovethe
ignitionkey.
2.Examinethecuttingendsofthebladecarefully,
especiallywheretheatandcurvedpartsofthe
blademeet(
Figure87).Sincesandandabrasive
materialcanwearawaythemetalthatconnects
theatandcurvedpartsoftheblade,checkthe
bladebeforeusingthemower.Ifwearisnoticed
(
Figure87),replacetheblade.
55
