Contents
Page
Introduction 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Before Operating 3. . . . . . . . . . . . . . . . . . . . . . . . .
While Operating 3. . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety and Instruction Decals 4. . . . . . . . . . . . . . . .
Specifications 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Specifications 6. . . . . . . . . . . . . . . . . . . . .
Optional Equipment 6. . . . . . . . . . . . . . . . . . . . . . .
Setup 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Head and Tank Assembly 7. . . . . . . . . . . . . . . . . . .
Electric Swivel Option
(Model No. 30728) 7. . . . . . . . . . . . . . . . . . . . . .
Broom Control Box and Wiring
(Electric Swivel Option) 7. . . . . . . . . . . . . . . . . .
Install the Push Arm 7. . . . . . . . . . . . . . . . . . . . . . .
Pump Mounting 8. . . . . . . . . . . . . . . . . . . . . . . . . .
Install Rear Weight 9. . . . . . . . . . . . . . . . . . . . . . . .
Before Operating 10. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adjust Brush Down Pressure 10. . . . . . . . . . . . . . . .
Broom Lift Chain Tension 10. . . . . . . . . . . . . . . . . .
Check Hydraulic System 10. . . . . . . . . . . . . . . . . . .
Operating Instructions 11. . . . . . . . . . . . . . . . . . . . . . . .
Operation 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Broom Angle 11. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Tips 11. . . . . . . . . . . . . . . . . . . . . . . . . . .
Ground Speed 11. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Curb Climbing and Trailer Loading 11. . . . . . . . . . .
Maintenance 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disconnecting the Broom from the Traction Unit 12
Changing Brush Elements 12. . . . . . . . . . . . . . . . . .
Broom Lift Chain Tension 13. . . . . . . . . . . . . . . . . .
Changing Hydraulic System Oil And Filter 13. . . . .
Servicing Castor Fork Bushings 13. . . . . . . . . . . . . .
Servicing Castor Wheel And Bearing 14. . . . . . . . .
The Toro General Commercial Products Warranty 16. .
Introduction
Read this manual carefully to learn how to operate and
maintain your product properly. The information in this
manual can help you and others avoid injury and product
damage. Although Toro designs and produces safe
products, you are responsible for operating the product
properly and safely.
Whenever you need service, genuine Toro parts, or
additional information, contact an Authorized Service
Dealer or Toro Customer Service and have the model and
serial numbers of your product ready. The two numbers are
stamped on a plate which is located on the broom.
Write the product model and serial numbers in the space
below:
Model No.
Serial No.
This manual identifies potential hazards and has special
safety messages that help you and others avoid personal
injury and even death. Danger, Warning, and Caution are
signal words used to identify the level of hazard. However,
regardless of the hazard, be extremely careful.
Danger signals an extreme hazard that will cause serious
injury or death if you do not follow the recommended
precautions.
Warning signals a hazard that may cause serious injury or
death if you do not follow the recommended precautions.
Caution signals a hazard that may cause minor or moderate
injury if you do not follow the recommended precautions.
This manual uses two other words to highlight information.
Important calls attention to special mechanical
information and Note: emphasizes general information
worthy of special attention.
