6
Specifications
General Specifications
Brush Filament Material Virgin polypropylene, high carbon wire or combination of both.
Brush Diameter 24 inches.
Sweeping Width Angle
Broom swings 30 degrees in both directions. 60 inches nominal sweeping width @
center position, 52 inches minimum sweeping width @ 30 degree swing.
Broom Swing/Control Manual pin position.
Broom Ground Pressure
Adjustment
Adjustment is with .5 inch spacers at the castor forks.
Brush Speed 220 rpm @ full engine RPM
Hydraulic Drive PTO driven pump. Tank has 10 U.S. gallon capacity.
Castor Wheels Two 8.5 inch x 3.5 inch pneumatic tires.
Weight 560 lbs.
Note: Specifications and design subject to change without notice.
Optional Equipment
Steel brush element Part No. 95–5942
Electric swivel option Model No. 30728
Brush rotation reversing option
