ProcedureDescription
Qty.
Use
Switchmountassembly
1
Controlcover
1
Fusemountplate1
Clipnut(#10)
3
Flasher1
Flangeheadscrew(#10x3/8inch)
1
Cabletie
1
Bracketmount2
Clipnut(1/4inch)
8
Switchmount
1
Multi-functionswitch
1
Switchclip(thick)
1
Switchclip(thin)
1
Switchplug
3
Rockerswitch1
Knob2
Fusecover1
Boltretainer2
Carriagebolt(1/4x2inches)
4
Flangelocknuts4
Cableties
2
Push-infastener
2
8
Flange-headsscrew(1/4x3/4inch)
6
Installthecontrolconsole.
Fuse(2A)
1
9
Fusedecal1
Installthedecal.
Plate2
Decal4
Hex-headscrew(1/4x2-1/2inches)
4
10
Locknut(1/4inch)
4
Installthedecal-mountingplates.
1
PreparingtheMachine
NoPartsRequired
Procedure
1.Parkthemachineonalevelsuface.
2.DisengagethePTOandengagetheparking
brake.
3.Lowerthecuttingunits.
4.Shutofftheengineandremovethekey.
5.Disconnectthenegative(-)batterycable.
2
DrillingtheMountingHoles
NoPartsRequired
DrillingtheHolesforthe
HeadlightsandtheWireHarness
1.Removethenutsfromthe2carriagebolts
securingtheheadlightstothetraction-unitframe
(Figure1).
2.Removethe2self-tappingboltssecuringthetop
oftheplatformshroudtotheframe(Figure1).
3.Unplugtheheadlightconnectorsandremove
theplatformshroudfromtheframe(Figure1).
4
