3. Align the hole in the back of the chute with the center
hole in the ring.
m-3277
1
4
5
2
3
Figure 4
1. Chute ring
2. Discharge chute
3. Chute handle
4. Carriage bolt
5. Locknut
Note: Y ou can rotate the chute ring for easier assembly .
4.
Install a carriage bolt and a locknut through the center
holes, with the locknut on the outside.
5. Install carriage bolts and locknuts through the
remaining holes, with the locknuts on the outside.
6. T ighten all locknuts securely.
Models 38441 and 38442 only
1. Set the dischar ge chute over the chute ring (Fig. 5).
2. Align the hole in the back of the chute with the center
hole in the ring (Fig. 5)
3. Install a carriage bolt and a locknut through the center
holes, with the locknut on the outside (Fig. 5)
Note: Y ou can rotate the chute ring for easier assembly .
4.
Install carriage bolts and locknuts through the
remaining holes, with the locknuts on the outside.
5. T ighten all locknuts securely.
1
2
636
Figure 5
1. Chute ring 2. Discharge chute
Installing the Chute Crank
Models 38441 and 38442 only
1. Insert the flattened end of the chute crank through the
hole in the shroud while aligning the mounting bracket
with the holes in the lower handle (Fig. 6).
2. Slowly rotate the crank until the flattened end fits into
the hidden gear opening and the chute ring turns with
the crank (Fig. 6).
3. Fully insert the plastic bushing into the hole in the
mounting bracket (Fig. 6).
4. Secure the mounting bracket to the handle with two
capscrews and locknuts (Fig. 6).
893
635
3
1
2
4
5
Figure 6
1. Chute crank
2. Mounting bracket
3. Gear
4.
Plastic bushing
5. Hidden gear opening
Installing the Handle
1. Cut the tie that secures the control cable to the lower
handle.
2.
Install the control bar on the upper handle as shown in
Figure 7 (models 38428 and 38429) or Figure 8
(models 38441 and 38442).
